7inch desktop computer portable mini pc with touch screen
- Portable mini pc built-in full plane IPS HD screen.
- IPS high definition screen multi-touch high resolution.
- Reflect the true color so that each pixel is visible.
- Mini pc computer can be seen in strong light without dazzling.
- Mini pc computer adopts a new manufacturing process and can be touched directly.
Functional features
Industry
Product Categories
Gallery
Product introduction:
- Rugged design, Leading innovation, improved work efficiency.
- Multifunctional super handheld touch Portable mini pc.
- Most configuration controls can be run, Making the operation control easy.
- IPS high definition screen multi-touch high resolution.
- Built-in full plane IPS HD screen.
- Reflect the true color so that each pixel is visible.
- Touch screen desktop computer can be seen in strong light without dazzling.
- Portable mini pc adopts a new manufacturing process and can be touched directly.
- Energy saving / high efficiency / stability / low consumption / 24h continuous and stable operation.
- No fan,no battery,l2VDC power supply design,more energy-saving.
- Portable mini pc was competent for high-intensity long-time operation, Long life, low power c wasonsumption, more environmental protection, can work 24hours without interruption.
- Quick response high accuracy no deviation.
- Precise touch 3ms response.
- No matter what operation, it can respond quickly.
- The accuracy rate is 99.9%, and there is no broken line offset in 5 point / 10 point touch.
- New screen / Ergonomic design / No short line offset.
Specification
Information Sheet:
MODEL | Portable mini pc SH703WD |
---|---|
Function | Win10 operating system, built-in office, supports the operation of various PC software |
Panel | 7inch(Touch Panel) |
Reolustion | 1280*800 IPS |
Body size (L x W x H) | 178*118*50mm |
Net weight | 424g |
CPU | Intel 8350 |
CPU frequency (RF) | 1.92GHz |
RAM | 2GB |
Memory | 32G |
Memory capacity expansion | Supports up to 32g TF card expansion |
Operating System | Win10 home operating system |
Button | Power button, volume up and down button |
Speaker | Built in horn x2 |
Bluetooth | Support Bluetooth 4.0 |
WiFi | 802.11b/g/n |
Interface Port | |
TF card port | |
Standard USB interface x4, USB 3.0 * 1, USB 2.0 * 3 | |
RJ45 | |
HDMI output | |
3.5mm dual channel audio output interface | |
DC power interface | |
GPU multimedia support (hardware decoding) | |
Music | MP3,WMA,WAV,OGG,FLAC,ALAC,APE,AAC,AC-3 |
Picture | JPG,JPEG,BMP,GIF,PNG... |
Video | MEPG 1/2/4,H.263/H.264,RMVB,WMV/VC-1,MVC,AVS,MJPEG.(Support1080P) |
Language | Chinese and English, support multiple languages |
Accessory | 5V 3A charger |
Cooling holes / metal fuselage / stable operation
- Efficient heat dissipation and silent operation.
- Multi-directional cooling hole design, and good thermal conductivity of the metal fuselage, long-term stable operation.
R&D / design / innovation / cultivation
- Portable mini pc.
- Redefining computer form in the new century.
- Our professional R&D and design team integrates modern microcomputers.
- Creative R&D and design, integration and innovative design create Touch screen desktop computer, Exquisite but not simple, say goodby to the bulky old computer!
Wireless WiFi / cable connection
- Diversified networking methods.
- The double choice is thoughtful!
- This computer has a variety of ways to connect to the network.
- You can choose WiFi or cable connection Support 100-1000m broadband access, work, Entertainment doesn’t have to worry about network speed anymore.
- It is suitable for routers of various brands.
Once again
Shiningltd. was established in 2004. It is a high-tech enterprise specialized in R&D, design, production, and sales of LCD digital signage.
Our factory has a number of automated production lines, covering the entire production system from product design, sheet metal processing, and assembly of finished products, to meet production requirements of different scales and OEM/ODM OEM cooperation.
Our products have completely independent intellectual property rights, currently provide 7-100 inch LCD digital signage products, including infrared touch screen, multimedia LCD advertising display, touch screen display, and so on.
Shiningltd introduced the ISO9001:2008 quality management system. Passed the CCC, CE, UL, ROHS, ERP energy-saving certification, to provide customers with quality products.
Through the perfect marketing network and convenient after-sales system, Our products are widely used in education, energy, finance, advertising industry, medical and other fields.
