Wall mount android poe tablet Product introduction:
- Unit: 275.36mm * 170.36mm * 25mm 0.74KG.
- Giftbox: 390mm * 220mm * 68mm 2.3KG.
- Carton 5pcs/CTN: 405mm * 363mm * 240mm 11.8kgs.
Wall mount android poe tablet Application scenario:
- SH1032WA wall mount android poe tablet
Information Sheet:
| SH1032WA | Wall mount android poe tablet |
|---|---|
| CPU | RK3288,Quad-core cortex A17,1.8G |
| RAM | 2GB |
| Internal memory | 16GB |
| Operation system | Android 8.1/9.0 |
| Touch screen | 10-Point capacitive touch |
| Panel | 10.1"LCD IPS panel |
| Resolution | 1280*800 |
| Active area | 217.4(H)x136.4mm(V) |
| Display mode | Normally black ,IPS |
| Viewing angle | 85/85/85/85(L/R/U/D) |
| Contrast ratio | 800 |
| Luminance | 280cd/m2 |
| Aspect Ratio | ,16:10 |
| WiFi | 802.11b/g/n |
| Ethernet | 100M/1000M ethernet |
| Buletooth | Bluetooth 4.0 |
| Card slot | SD card |
| USB | USB Host |
| Micro USB | Micro USB OTG |
| USB | USB for serial |
| RJ45 with POE | RJ45 |
| POE | IEEE802.3at |
| Power jack | DC power input |
| Earphone | 3.5mm earphone |
| Video format | MPEG-1,MPEG-2,MPEG-4,H.263,H.264,VC1,RV etc.,support up to 4K |
| Audio format | MP3/WMA/AAC etc. |
| Photo | jpeg |
| VESA | 204.5mm |
| NFC | 13.56M(Optional) |
| Camera | 2.0M/P,Front camera/Binocular camera(optional) |
| Microphone | Microphone |
| Speaker | 2*1.5W |
| LED Light bar | LED light bar with RGB and mixed color |
| Working temp | 0--40degree |
| Certificates | CE/FCC/RoHS |
| Language | Multi-language |
| Adapter | Adapter,12V/1.5A |
| User manual | yes |
