Application scenario:
Android digital signage touch screen as displaying marketing messages and promotions including; branding, digital brochures, video playback, website, interactive flash presentation, product specifications and features.
Product introduction:
- Supports all video, file, network streaming media format
- Pre-installed native Andrews system, built-in google Play Store and other Google applications
- Also pre-installed custom system, including customized Andrews system or raspberry system
- Equipped touch-screen with full-glass structure, with ultra-high sensitivity, and support all OS system
Information Sheet:
| SH1503AD | 15.6inch Android digital signage touch screen |
|---|---|
| Screen size: | 15.6inch |
| Backlight: | LED |
| Angle: | 170/170 UD/LR |
| Brightness: | 300cd/m2 |
| Aspect ratio: | 16:09 |
| Display Specifications: | 1920X1080 |
| System: | Android 4.4/5.1 |
| CPU: | RK3368 |
| Storage: | EMMC 8Gb |
| Memory: | DDR 1G |
| Support video format: | AVI, MKV，WMV，MOV，MP4，DAT，VOB，PMP,MPEG，FLV，ASF ，TS， TP，3GP，MPG |
| Support pic format: | BMP、JPEG、PNG、GIF |
| Touch function: | 10 point touch, finger or touch pen, Reaction time as 4ms, Durability ≥ 50 million times touch, Full-angle anti-glare |
| Optional feature: | Bluetooth 4.0, R232 / R485 port |
| Accessories: | AC power cable (With Power Adapter), Remote control, Antenna, Wall bracket, User manual; |
| Power: | AC110-240V (Input:24W Standby<1W) |
| Autio output: | 8Ω10W * 2 |
| Port: | DC12V*1，USB*1，OTG*1，WLIN RJ45*1 |
| Material: | Front toughened glass / Aluminum frame / Steel plate material |
| Color: | Front frame silver / Back shell black |
| Cabinet Size: | 388*237*37mm |
| Function: | Supports all video, file, network streaming media format; |
| Pre-installed native Andrews system, built-in google Play Store and other Google applications | |
| Also pre-installed custom system, including customized Andrews system or raspberry system | |
| Equipped touch-screen with full-glass structure, with ultra-high sensitivity, and support all OS system |
