17.3inch wifi touch android screens
Application scenario:
- 17.3inch wifi touch android screens Widely used for bank, market, company, hospital, hotel, etc.
Product introduction:
- Unit: 427.76mm * 268mm * 152.95mm 2.14kgs.
- Giftbox: 492mm * 330mm * 170mm.
- Carton 2pcs/CTN: 507mm * 358mm * 350mm 4.2kgs.
Information Sheet:
System & Display
| CPU | Quad core cortex A17,1.8G,RK3288 |
|---|---|
| RAM | 2GB |
| Internal memory | 16GB |
| Operation system | Android 8.1/10.1 |
| Touch screen | 10-Point capacitive touch |
| Panel | 17.3"LCD IPS panel |
| Resolution | 1920*1080 |
| Active area | 381.89(H)x214.81mm(V) |
Network & Interface
| WiFi | 802.11b/g/n |
|---|---|
| Ethernet | 10M/100M ethernet |
| Buletooth | Bluetooth 4.0 |
| Card slot | TF card |
| USB x 2 | USB Host |
| Micro USB | Micro USB OTG |
| HDMI | HDMI output |
| RJ45 | RJ45 |
| Serial port | USB for serial port |
| Power jack | DC12V power input |
| Earphone | 3.5mm earphone |
Other
| NFC | Optional, ISO/IEC 14443 type A,type B cards |
|---|---|
| Speaker | 2*2W |
| Camera | 2.0M/P,Front camera |
| MIC | Built-in MIC |
| Power consumption | 20W |
| Working temp | 0--40degree |
| Certificates | CE/FCC/RoHS |
| Language | Multi-language |
| Adapter | Adapter,12V/2A |
| User manual | yes |
