HD video smart android TV player box 4k
If you’re looking to create the ideal digital signage solution, look no further than our range of HD video smart android TV player box 4k.
We offer an unrivaled level of connectivity, allowing Android box 4k to connect to a wide variety of professional LCD displays and monitors. Our Android tv box 4k can connect to the internet using LAN, WiFi or even 4G – making them quick and convenient to use no matter where you are.
Thanks to our cloud-based CMS software, you can effortlessly update your Android TV Player Box from anywhere in the world with an internet connection. The easy-to-use interface lets you control your entire network with ease, allowing you to create groups and update multiple devices simultaneously.
We offer a wide range of templates to ensure that you can combine images, videos, RSS, and text on-screen simultaneously. Choose the perfect signage solution today with our HD video box.
Android TV player box’s CMS publishing system:
Background server management software, set parameters, make the playlist, make split-screen files, support 2 video zones, weather, streaming media, webpage, Word, Excel, PDF, PPT, txt file display on one screen, download server video sources in real-time, autoplay after download completed.
Functional features
Gallery
Specification
Information Sheet:
If need more detailed and updated specifications, or need customized requirements, Please contact us
| Model number | SH-RK3568A |
|---|---|
| Enclosure Color | Black/Silver |
| Material | Super strong and light aluminum alloy material, integrated fanless structure heat dissipation design |
| Processor | RK3568 (Cortex-A55x4) quad-core processor, the main frequency can reach up to 2.0GHz |
| Ram | 2GB Standard ( 4GB optional) |
| Storage | 16GB Standard (32GB/64GB optional) |
| Android OS | Android 11.0 |
| Decoding resolution | Support up to 1920*1080 Resolution |
| Network | WIFI /BT 4.0/WAN LINE (4G optional, Built-in MINI PCI-E interface, can support 4G Internet access, does not support analog or digital calls) |
| I/O Ports | DC Jack*1, RJ45*1(1000M)*1, TF*1 , USB 3.0*1, USB Host *1, Audio out*1, 1* HDMI Output (supports 4Kx2K@60Hz) |
| Power Supply | DC 12V/3A |
| Play mode | Support multiple playback modes such as loop, timing, intermission, etc. |
| Audio and video output | Support headphone audio output, support left and right channel output, built-in dual 4R/2.5W, 8R/1.5W power amplifier |
| RTC real time clock | Support |
| Video playback | Support wmv, avi, flv, rm, rmvb, mpeg, ts, mp4, etc. |
| Timer switch | Support |
| Image Format | Support BMP, JPEG, PNG, GIF |
| System Upgrade | Support local USB upgrade |
| Remote head | Support (optional) |
| Power Consumption | 10W |
| Dimensions(mm) | TBD |
| Operating Temperature | 0°C to 60°C |
| Storage Temperature | -45°C to 85°C |
| Humidity | Operating: 20% to 80%, Storage: 5% to 95% |
| Mounting Options(VESA) | Support |
| Regulatory approvals and declarations | UL, FCC (US) , CE (Europe) ,CCC(China) |
| MTBF | ≥50000h |
| Spare part | Power Supply, WiFi Antenna |
Once again
FAQ guide for Android TV player box:
How should I place an order for Android TV player box?
What is the average price of Android TV player box?
So please contact us for more accurate order quotation.
What are the products similar to Android TV player box?
