Touch computer touchpad monitor for sale
Touch computer monitor adopts to a fanless cooling system for heating dissipation, and energy efficient CPU for optimal performance. They are widely used in Industrial Internet of Things (IIoT), Machine-to-Machine (M2M), intelligent building automation, HVAC control, access control, check-in system, interactive security systems.
Touch computer built for demanding industrial, commercial, and military applications. Other 7~21.5″ for optional, and support tabletop, panel mount, embedded, wall-hanging, and VESA mounting, and operating system supports Win 7, Win 8, Win10, or Linux, provides incredible flexibility and high adaptability. Gigabit Ethernet is available. The ultra-thin 3mm front bezel makes it suitable to be placed at cabinets for embedded mount and panel mount.
Touch computer monitor features:
● 21.5” Projective capacitive multi-touch screen.
● A fanless heat-dissipation system with ultra-low power consumption.
● Expansion for digital I/O.
● Front bezel with IP65 Dust and Waterproof.
● TFT LCD screen with 16:9 aspect ratio and LED backlight.
● Aluminum alloy housing.
● Supports panel mount, wall mount, VESA arm, and desktop stand.
● Offer programmable OSD function key on the back panel.
● Industrial-grade motherboard, 7/24 long-term operation in harsh conditions.
● Special design for DC power port with anti-shedding, prolong its service life.
● Triple protection: moisture-proof, explosion-proof, and flameproof.
● support customized functional module.
Computer touchpad product features:
• 21.5-inch FHD 1920 x 1080 (16:9)
• IP65 surface dustproof and waterproof
• Aluminum alloy housing, excellent corrosion resistance, fanless for heat-dissipation
• Support DC-in 12V
• Support wide operating temperature -20°C~70°C
• Highly modularized design for easy upgrade
• Highly flexible I/O and expansion capabilities
• Support embedded mount, panel mount, desktop mount, VESA mount 75 x 75 /100 x 100mm
• CE, RoHS approved
Functional features
Gallery
Specification
Information Sheet:
| SH2111AIO(21.5inch) | touch computer |
|---|---|
| Hardware parameters | |
| CPU | Intel J1900(Can UpgradeI3/I5/I7) |
| Frequency | Quad-core and four-thread main frequency 2.0GHz |
| Chipest | Intel Bay trail SOC |
| Memory | DDR3 4GB |
| Storage | SSD 128G |
| Audio | Integrated Realtek ALC662 HD decoding control chip |
| Network | Integrated RTL8111E Gigabit network card chip |
| Wireless network | 2.4G wireless module (5G module optional) |
| Graphics | HD Graphics |
| System | WIN10 professional edition |
| Built-in speaker | 8Ω3W （Up to 5w audio output support ） |
| System Monitoring / Watchdog | Support for CPU temperature detection, fan speed, and system temperature |
| Display parameters | |
| Size | 21.5inch |
| Panel | Industrial A-gauge LCD display panel |
| Backlight | LED backlight |
| Display ratio | 16:9 |
| Resolution | 1920*1080 |
| Contrast | 300:1 |
| Brightness | 300CD/M2（500/800/1000CD optional） |
| Life | ≥50000H |
| Color | 16.7M |
| Angle | 160° |
| Touch configuration | |
| Touch form | Projection capacitive touch (optional non-touch and resistive touch) |
| Writing Mode | Finger or capacitive pen |
| Touch process | G+G |
| Surface hardness | 6H |
| Life | ≥5000 million times touch |
| Light transmittance | ≥87% |
| Interface parameters | |
| Power | DC5.5*2.5mm |
| HDMI | HDMI*1 |
| VGA | VGA*1 (support for dual display) |
| RS232 | RS232*2 |
| USB | USB2.0*3 USB3.0*1 |
| Internet | RJ45*1 |
| Audio | MIC-IN*1 LINE-OUT*1 |
| RS485 | None（Can extended 1-2RS485） |
| GPIO | None（Can customizable extension for a 7-way gpio ） |
| Antenna | SMA（can Extended bluetooth） |
| GPS | None（can Extended） |
| 3G/4G | None（can Extended） |
| Other parameters | |
| Power input | 12V-5A Industrial external power adapter |
| Max power consumption | ≤48W |
| Working temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ |
| relative humidity | 5%-85% |
| Material | aluminium alloy |
| Levels of protection | Front panel IP65 dustproof and waterproof / rear cover fully enclosed and dustproof IP40 |
| 1Warranty | 1 year |
