Information Sheet:
| Model: | SH1503AIO | 15.6inch LCD all in one industrial touchscreen monitor |
|---|---|---|
| Device parameter: | Screen size: | 15.6inch |
| Backlight: | LED | |
| Angle: | 170/170 UD/LR | |
| Brightness: | 300cd/m2 | |
| Aspect ratio: | 16:09 | |
| Display Specifications: | 1920X1080 | |
| System: | Windows7 | |
| CPU: | Intel IVB 3217U 1.8GHz | |
| Memory: | Kingston DDR3 1600 4G(8G for option) | |
| Storage: | M sata SSD 120G | |
| Graphics card: | CPU integrated Graphics 4000 display | |
| Audio decode: | Integrated 6 channel sound, support HiFi 5.1 | |
| Touch function: | 10 point touch, finger or touch pen, Reaction time as 4ms, Durability ≥ 50 million times touch, Full-angle anti-glare | |
| Optional feature: | Bluetooth 4.0, R232 / R485 / R422 port | |
| Overall parameters: | Accessories: | AC power cable (With Power Adapter), Antenna, Wall bracket, User manual; |
| Power: | AC110-240V (Input:24W Standby<1W) | |
| Autio output: | 8Ω10W * 2 | |
| Port: | DC IN*1，HDMI OUT*1，VGA OUT*1，USB3.0*2，USB2.0*2, RJ45*1，AUDIO*2 | |
| Material: | Front toughened glass / Aluminum frame / Steel plate material | |
| Color: | Front frame silver / Back shell black | |
| Cabinet Size: | 388*237*37mm | |
| Function: | Supports all video, file, network streaming media format; | |
| RTC regular boot, power on automatically boot | ||
| Pre-installed custom system, including Chrome OS、Windows、Mac and Linux | ||
| With X86 architecture, all configurations can be customized according to customer, including CPU, Memory, Storage and so on | ||
| Equipped touch-screen with full-glass structure, with ultra-high sensitivity, and support all OS system |
If need more detailed and updated specifications, or need customized requirements, Please contact us
Gallery
Features
15.6inch LCD all in one industrial touchscreen monitor
15.6inch LCD all in one industrial touchscreen monitor is the perfect solution for those who require interactive applications. It has been thoughtfully designed to prioritize both durability and performance, ensuring that it can effortlessly keep up with the user’s needs. The best part is that it can be customized to perfectly fit your desired Panel PC.
Not only is this industrial touchscreen monitor suitable for personal use, but it also caters to a wide range of industries. It is an excellent fit for conference room presentations, video teleconferencing, or any application where a powerful PC is required to support a large LCD digital display. Moreover, it has a highly customizable industrial touchscreen that can be tailored to meet your specific requirements.
If you’re in need of a reliable and powerful touch screen industrial monitor for your interactive applications, then the 15.6inch LCD all in one industrial touchscreen monitor is definitely worth considering.
Our industrial touchscreen monitor is 15.6 inches with a smooth glass design and a clear display for great viewing. It’s really durable and can withstand tough weather, making it a great investment for your business. You can easily customize it to suit your needs by selecting the CPU, memory, graphics card, or SSD. It comes with standard VESA holes that allow you to mount it on a wall, and you can use multiple fingers to control it.
Yes, Our professional R&D and design team integrates modern industrial touchscreen all in one.
Creative R&D and design, integration and innovative design create Touch screen desktop computer, Exquisite but not simple!
Once again
FAQ guide for industrial touchscreen:
How should I place an order for industrial touchscreen?
What is the average price of industrial touchscreen?
So please contact us for more accurate order quotation.
What are the products similar to industrial touchscreen?
