Features
OEM smart mini 9 inch z8350 window 10 touch screen desktop computer SH903WD
Touch screen desktop computer with Windows 10 Multiple mainstream operating systems.
Intel Mainstream chip manufacturers and core technologies have deeply developed.
And customized a variety of operating systems for education.
Provide various solutions in medical treatment, urban public transportation, smart home, and other fields.
Functional features
Industry
Gallery
Product introduction:
Rugged design, Leading innovation, improved work efficiency.
Multifunctional super handheld touch mini pc computer.
Most configuration controls can be run, Making the operation control easy.
IPS high definition screen multi-touch high resolution.
Built-in full plane IPS HD screen.
Reflect the true color so that each pixel is visible.
Touch screen desktop computer can be seen in strong light without dazzling.
Touch screen desktop computer adopts a new manufacturing process and can be touched directly.
Energy saving / high efficiency / stability / low consumption
24h continuous and stable operation.
No fan，no battery，l2VDC power supply design，more energy-saving.
Touch screen desktop computer was competent for high-intensity long-time operation, Long life, low power c wasonsumption, more environmental protection, can work 24hours without interruption.
Quick response high accuracy no deviation.
Precise touch 3ms response.
No matter what operation, it can respond quickly.
The accuracy rate is 99.9%, and there is no broken line offset in 5 point / 10 point touch.
New screen / Ergonomic design / No short line offset.
Specification
Information Sheet:
| MODEL | Touch screen desktop computer SH903WD |
|---|---|
| Function | Minipc box, win10 operating system, built-in genuine office, supporting the operation of various PC and Android Software |
| Panel | 9inch(Touch Panel） |
| Reolustion | 1920*1200 IPS |
| Body size (L x W x H) | 217x148x60mm |
| Net weight | 650g |
| CPU | Intel X5-Z8350 |
| CPU frequency (RF) | 1.84 GHz |
| RAM | 2GB |
| Memory | 32G |
| Memory capacity expansion | Supports up to 32g TF card expansion |
| Operating System | Win10 home operating system |
| Button | Power button, volume up and down button |
| Speaker | Built in horn x2 |
| Bluetooth | Support Bluetooth 4.0 |
| WiFi | 802.11b/g/n |
| Interface Port | |
| TF card port | |
| Standard USB interface x4, USB 3.0 * 1, USB 2.0 * 3 | |
| RJ45 | |
| HDMI output | |
| 3.5mm dual channel audio output interface | |
| DC power interface | |
| GPU multimedia support (hardware decoding) | |
| Music | MP3，WMA，WAV，OGG，FLAC，ALAC，APE，AAC，AC-3 |
| Picture | JPG,JPEG,BMP，GIF,PNG... |
| Video | MEPG 1/2/4，H.263/H.264，RMVB，WMV/VC-1，MVC，AVS，MJPEG.（Support1080P） |
| Language | Chinese and English, support multiple languages |
| Accessory | 12V 2.4A charger |
Cooling holes / metal fuselage / stable operation
- Efficient heat dissipation and silent operation.
- Multi-directional cooling hole design, and good thermal conductivity of the metal fuselage, long-term stable operation.
R&D / design / innovation / cultivation
- Touch screen desktop computer.
- Redefining computer form in the new century.
- Our professional R&D and design team integrates modern microcomputers.
- Creative R&D and design, integration and innovative design create Touch screen desktop computer, Exquisite but not simple, say goodby to the bulky old computer!
Wireless WiFi / cable connection
- Diversified networking methods.
- The double choice is thoughtful!
- This computer has a variety of ways to connect to the network.
- You can choose WiFi or cable connection Support 100-1000m broadband access, work, Entertainment doesn’t have to worry about network speed anymore.
- It is suitable for routers of various brands.
Once again
Shiningltd. was established in 2004. It is a high-tech enterprise specialized in R&D, design, production, and sales of LCD digital signage.
Our factory has a number of automated production lines, covering the entire production system from product design, sheet metal processing, and assembly of finished products, to meet production requirements of different scales and OEM/ODM OEM cooperation.
Our products have completely independent intellectual property rights, currently provide 7-100 inch LCD digital signage products, including infrared touch screen, multimedia LCD advertising display, touch screen display, and so on.
Shiningltd introduced the ISO9001:2008 quality management system. Passed the CCC, CE, UL, ROHS, ERP energy-saving certification, to provide customers with quality products.
Through the perfect marketing network and convenient after-sales system, Our products are widely used in education, energy, finance, advertising industry, medical and other fields.
