Touch screen information kiosk SH4976AD
Touch screen information kiosk as displaying marketing messages and promotions including; branding, digital brochures, video playback, website, interactive flash presentation, product specifications and features.
1. Network patrol allows maintenance personnel who go out for inspection to control the remote control to record the arrival time and report status. Supervise the attendance of maintenance personnel.
2. Through the live broadcast server, media materials can be played synchronously to some or all of the player boxes.
3. Able to control the playback terminal and publish rolling subtitle information through the SMS platform.
4. The Advertising android display has more perfect network terminal fault monitoring, which can automatically generate fault dispatch orders and send them to maintenance personnel.
Functional features
Gallery
Specification
Touch screen information kiosk
- 49 inch WLED backlight
- 3mm tempered glass covered for front protection,aluminum frame rounded,cold-rolled plate material
- Android(4.4/5.1)
Touch screen information kiosk
Information Sheet:
| Model | SH4976AD | Touch screen information kiosk |
|---|---|---|
| Display Specifications | Display Parameters | 49 inch WLED backlight |
| Resolution | 1920*1080 | |
| Display ratio | 16:9 | |
| Brightness | 350cd/m2 | |
| Contrast | 1400:1 | |
| Angle | 178/178° | |
| Color | 16.7M | |
| Response time | 5ms | |
| Life | 50000h | |
| Function Specifications | System | Android(5.1/6.0) |
| CPU | Rockchip quad core RK3288 | |
| Flash | standard EMMC 2G | |
| Memory | standard DDR 8G | |
| Network | WIFI/WAN LINE（3G/4G optional） | |
| External ports | DC12V*1,USB*1,OTG*1,RJ45*1 | |
| Touch | Infrared touch | |
| Expansion peripherals | ID card reader, one / two-dimensional code scanner, printer, IC card reader, infrared sensor, etc. | |
| Video format | HD H.264 2160P video decoding, multi-format full HD video decoding, including MPEG1 / 2, MPEG4 SP / ASP GMC, H.263, H.264, VP6 / 8, AVS jizun, JPEG / MJPEG, etc .; BD directory, BD ISO and BD m2ts video decoding; 264 High Profile 1080P @ 30fps or 720p @ 60fps encoding; 3840x1080 @ 30fps 3D decoding, support BD / SBS / TAB / FP; support RTSP, HTTP, HLS, RTMP, MMS flow Media agreement | |
| Multimedia publishing software | System Center server using B / S architecture, the headquarter is the center,second regional institutions set up second servers, zoning management authorized, player terminal C / S architecture set up through network. | |
| Machine Specifications | Operating temperature | 0℃ to 50℃ |
| Operating humidity | 10 to 80％ | |
| Voltage | AC110V~240V | |
| Power consumption | 85W | |
| Standby Power | 8W | |
| Audio output | 8Ω10WX 2 | |
| Material | 3mm tempered glass covered for front protection,aluminum frame rounded,cold-rolled plate material |
Once again
FAQ guide for Touch screen information kiosk:
How should I place an order for Touch screen information kiosk?
What is the average price of Touch screen information kiosk?
So please contact us for more accurate order quotation.
Can I get the brand logo printed on Touch screen information kiosk?
Please contact us to confirm the logo design, color and location you require;
Can you provide ODM / OEM or customized services to Touch screen information kiosk?
Yes, we can do OEM and ODM. We also provide customers with different customized services, such as appearance color, built-in camera, base mobile device, built-in designated printer, various card readers, and other designs…
Do you have software for Touch screen information kiosk?
Yes, we will provide application software with complete intellectual property rights according to different interaction schemes, all based on Android and windows operating systems;
Please contact us for details…
