SH1011AIO(10.4inch)
Information Sheet:
| SH1011AIO | Touch Panel PC |
|---|---|
| Hardware parameters | |
| CPU | Intel J1900(Can UpgradeI3/I5/I7) |
| Frequency | Quad-core and four-thread main frequency 2.0GHz |
| Chipest | Intel Bay trail SOC |
| Memory | DDR3 4GB |
| Storage | SSD 128G |
| Audio | Integrated Realtek ALC662 HD decoding control chip |
| Network | Integrated RTL8111E Gigabit network card chip |
| Wireless network | 2.4G wireless module (5G module optional) |
| Graphics | HD Graphics |
| System | WIN10 professional edition (WIN 7, Linux optional) |
| Built-in speaker | 8Ω3W （Up to 5w audio output support ） |
| System Monitoring / Watchdog | Support for CPU temperature detection, fan speed, and system temperature |
| Display parameters | |
| Size | 10.4inch |
| Panel | Industrial A-gauge LCD display panel |
| Backlight | LED backlight |
| Display ratio | 4:3 |
| Resolution | 1024*768 |
| Contrast | 300:1 |
| Brightness | 300cd/m²（500/800/1000cd/㎡ optional） |
| Life | ≥50000H |
| Color | 16.7M |
| Angle | 160° |
| Touch configuration | |
| Touch form | Projection capacitive touch (optional non-touch and resistive touch) |
| Writing Mode | Finger or capacitive pen |
| Touch process | G+G |
| Surface hardness | 6H |
| Life | ≥5000 million times touch |
| Light transmittance | ≥87% |
| Interface parameters | |
| Power | DC5.5*2.5mm |
| HDMI | HDMI*1 |
| VGA | VGA*1 (support for dual display) |
| RS232 | RS232*2 |
| USB | USB2.0*3 USB3.0*1 |
| Internet | RJ45*1 |
| Audio | MIC-IN*1 LINE-OUT*1 |
| RS485 | None（Can extended 1-2RS485） |
| GPIO | None（Can customizable extension for a 7-way gpio ） |
| Antenna | SMA（can Extended bluetooth） |
| GPS | None（can Extended） |
| 3G/4G | None（can Extended） |
| Other parameters | |
| Power input | 12V-5A Industrial external power adapter |
| Max power consumption | ≤48W |
| Working temperature | -10℃～50℃ |
| Storage temperature | -20℃～70℃ |
| relative humidity | 5%-85% |
| Material | aluminium alloy |
| Levels of protection | Front panel IP65 dustproof and waterproof / rear cover fully enclosed and dustproof IP40 |
| 1Warranty | 1 year |
If need more detailed and updated specifications, or need customized requirements, Please contact us
Features
Rugged 10inch Industrial HMI Touch Panel PC
When it comes to choosing the right device for your industrial needs, the task can be daunting. With such a wide range of options available, it’s easy to feel overwhelmed and unsure of where to begin. Thankfully, the 10 inch industrial hmi touch panel pc windows 10 embedded has been designed to meet the needs of even the most demanding industrial environments. Its rugged build ensures that it can withstand harsh conditions and extreme temperatures, while its durable features guarantee that it will work hard for you day in and day out.
The 10.4inch IPS LED panel display is not only visually stunning but highly compatible with a wide range of software systems, allowing for easy customization. Whatever your needs may be, 10 inch industrial hmi touch panel pc can be tailored to suit them thanks to a variety of colors and interfaces to choose from. With its waterproof and dust-proof rating of IP65, you can rest assured that it is built to withstand even the harshest of elements.
One of the many benefits of 10 inch industrial hmi touch panel pc windows 10 embedded is its resistance to vibrations and interferences, making it the perfect choice for those working in outdoor environments or those who need to embed it into equipment. With its many functional modules, such as a dual camera and RFID reader, the possibilities for customization are endless. Overall, industrial hmi touch panel pc windows 10 embedded truly has it all and is the perfect addition to any industrial environment.
Yes, the touch panel PC is customizable. The device offers customizable options for working temperature, voltage, and high brightness for sunlight readability. It also supports various functional module customization, such as the inclusion of a barcode scanner, IC card reader, ID card reader, RFID reader, dual camera, and more.
Functional features
